| Part number: | PMB1854560KBP |
| Description: | CAP FILM 5.6UF 10% 850VDC SCREW |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 72 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Rectangular Box |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 85°C |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Termination | Screw Terminals |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 500V |
| Voltage Rating - DC | 850V |
| Height - Seated (Max) | 2.264" (57.50mm) |
| Capacitance | 5.6 µF |
| ESR (Equivalent Series Resistance) | 1.6 mOhms |
| Size / Dimension | 2.264" L x 1.496" W (57.50mm x 38.00mm) |
|
