| Part number: | MG-B2-10-L |
| Description: | SWITCH MAGNETIC SPST-NC 250MA |
| Manufacturer | Magnasphere Corp. |
| Encapsulation | Bulk |
| Quantity | 100 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Magnasphere Corp." |
| Mounting Type | Through Hole |
| Circuit | SPST-NC |
| Type | Magnasphere® Magnetic |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Length - Overall | 0.723" (18.36mm) |
| Height Above Board | 0.244" (6.20mm) |
| Current - Switching | 250mA (DC) |
| Voltage - Switching DC | 30 V |
| Size - Body | 0.198" Dia x 0.244" L (5.03mm x 6.20mm) |
| Operate Range | 21.41mm |
| Release Range | 22.91mm |
| Capacitance | 1 pF |
|
