| Part number: | ELBG250ELL792AMN3S |
| Description: | CAP ALUM 7900UF 30% 25V RAD TH |
| Manufacturer | United Chemi-Con |
| Encapsulation | Bulk |
| Quantity | 500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "United Chemi-Con" |
| Tolerance | 0%, +30% |
| Package / Case | Radial, Can |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 105°C |
| Applications | Automotive |
| Lead Spacing | 0.295" (7.50mm) |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Height - Seated (Max) | 1.299" (33.00mm) |
| Capacitance | 7900 µF |
| Voltage - Rated | 25 V |
| Impedance | 24 mOhms |
| Ripple Current @ Low Frequency | 2.975 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.5 A @ 100 kHz |
|
