| Part number: | GSA100AA60 |
| Description: | IGBT MODULE 100A SINGLE 600V LOW |
| Manufacturer | SANREX |
| Encapsulation | Tube |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "SANREX" |
| Package / Case | SOT-227-4, miniBLOC |
| Mounting Type | Chassis Mount |
| Input | DC |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 1.5V @ 15V, 100A |
| NTC Thermistor | No |
| Supplier Device Package | SOT-227 |
| Current - Collector (Ic) (Max) | 100 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Power - Max | 500 W |
| Current - Collector Cutoff (Max) | 100 µA |
| Input Capacitance (Cies) @ Vce | 6.69 nF @ 10 V |
|
