| Part number: | ESY128M035AL8AA |
| Description: | CAP ALUM RAD 105C LOW ESR/IMPD |
| Manufacturer | TOKIN (KEMET) |
| Encapsulation | Bulk |
| Quantity | 1200 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "TOKIN (KEMET)" |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Size / Dimension | 0.512" Dia (13.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Applications | General Purpose |
| Lead Spacing | 0.197" (5.00mm) |
| ESR (Equivalent Series Resistance) | 16mOhm @ 100kHz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Capacitance | 1200 µF |
| Voltage - Rated | 35 V |
| Impedance | 16 mOhms |
| Ripple Current @ Low Frequency | 2.632 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.29 A @ 100 kHz |
|
