| Part number: | 1513164-1 |
| Description: | RF ANT 2.4GHZ/5.5GHZ MOLDED SLD |
| Manufacturer | TE Connectivity AMP Connectors |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 450 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "TE Connectivity AMP Connectors" |
| Mounting Type | Surface Mount |
| Frequency Range | 2.4GHz ~ 2.483.5GHz, 5.15GHz ~ 5.875GHz |
| Applications | Bluetooth, WLAN, Zigbee™ |
| Gain | 4dBi |
| Termination | Solder |
| Number of Bands | 2 |
| VSWR | 2.5 |
| Antenna Type | Molded |
| Height (Max) | 0.236" (6.00mm) |
| Frequency Group | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) |
| Frequency (Center/Band) | 2.4GHz, 5.5GHz |
| RF Family/Standard | 802.15.4, Bluetooth, WiFi |
| Power - Max | 10 W |
|
