| Part number: | SPM0408LE5H-TB-6 |
| Description: | MIC MEMS ANALOG OMNI -18DB |
| Manufacturer | Knowles |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 4800 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Knowles" |
| Output Type | Analog |
| Size / Dimension | 0.186" L x 0.148" W (4.72mm x 3.76mm) |
| Sensitivity | -18dB ±3dB @ 94dB SPL |
| Shape | Rectangular |
| Type | MEMS (Silicon) |
| S/N Ratio | 63dB |
| Termination | Solder Pads |
| Direction | Omnidirectional |
| Port Location | Bottom |
| Height (Max) | 0.053" (1.35mm) |
| Impedance | 200 Ohms |
| Current - Supply | 350 µA |
| Voltage Range | 1.5 V ~ 5.5 V |
| Frequency Range | 100 Hz ~ 10 kHz |
|
