| Part number: | WIP252012S-4R7MLDG |
| Description: | POWER INDUCTOR 2520 4.7UH 20% DC |
| Manufacturer | INPAQ Technology Co., Ltd. |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "INPAQ Technology Co., Ltd." |
| Tolerance | ±20% |
| Package / Case | 1008 (2520 Metric) |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Wirewound |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 180mOhm Max |
| Frequency - Self Resonant | 35MHz |
| Current - Saturation (Isat) | 2A |
| Material - Core | Metal |
| Inductance Frequency - Test | 1 MHz |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.047" (1.20mm) |
| Inductance | 4.7 µH |
| Current Rating (Amps) | 1.5 A |
|
