| Part number: | 15M223J |
| Description: | MOLDED UNSHIELDED RF COILS AXIAL |
| Manufacturer | Gowanda |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 2500 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Gowanda" |
| Tolerance | ±5% |
| Package / Case | Axial |
| Size / Dimension | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) |
| Mounting Type | Through Hole |
| Shielding | Unshielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 105°C |
| DC Resistance (DCR) | 7.45Ohm Max |
| Q @ Freq | 65 @ 790kHz |
| Frequency - Self Resonant | 6.2MHz |
| Material - Core | Iron Powder |
| Inductance Frequency - Test | 790 kHz |
| Supplier Device Package | Axial |
| Inductance | 220 µH |
| Current Rating (Amps) | 103 mA |
|
