| Part number: | TB0010V-500-10GR |
| Description: | 10 POLES, SCREW TYPE, VERTICAL, |
| Manufacturer | CUI Devices |
| Encapsulation | Box |
| Quantity | 200 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "CUI Devices" |
| Features | Interlocking (Side) |
| Color | Green |
| Mounting Type | Through Hole |
| Wire Gauge | 14-22 AWG |
| Pitch | 0.197" (5.00mm) |
| Operating Temperature | -40°C ~ 105°C |
| Mating Orientation | Vertical with Board |
| Positions Per Level | 10 |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Screw Thread | M3 |
| Wire Termination | Screw |
| Current | 16 A |
| Number of Levels | 1 |
| Voltage | 250 V |
|
