| Part number: | SDS120J027H3-ISATH |
| Description: | DIODE 1200V-27A TO247-2L |
| Manufacturer | Luminus Devices |
| Encapsulation | Tube |
| Quantity | 300 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Luminus Devices" |
| Package / Case | TO-247-2 |
| Mounting Type | Through Hole |
| Speed | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns |
| Technology | SiC (Silicon Carbide) Schottky |
| Capacitance @ Vr, F | 1761pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 77A |
| Supplier Device Package | TO-247-2L |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.8 V @ 27 A |
| Current - Reverse Leakage @ Vr | 80 µA @ 1200 V |
|
