| Part number: | PF0553.822NLT |
| Description: | INDUCT ARRAY 2 COIL 8.9UH SMD |
| Manufacturer | Pulse Larsen Antenna |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 400 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Pulse Larsen Antenna" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| Height | 0.315" (8.00mm) |
| Number of Coils | 2 |
| Inductance - Connected In Series | 35 µH |
| Inductance - Connected In Parallel | 8.9 µH |
| Current Rating - Parallel | 6.2 A |
| Current Rating - Series | 3.1 A |
| Current Saturation - Parallel | 12 A |
| Current Saturation - Series | 6.1 A |
| DC Resistance (DCR) - Parallel | 15mOhm Max |
| DC Resistance (DCR) - Series | 62mOhm Max |
|
