| Part number: | PF0553.823NLT |
| Description: | INDUCT ARRAY 2 COIL 80UH SMD |
| Manufacturer | Pulse Larsen Antenna |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 400 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Pulse Larsen Antenna" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| Height | 0.315" (8.00mm) |
| Number of Coils | 2 |
| Inductance - Connected In Series | 320 µH |
| Inductance - Connected In Parallel | 80 µH |
| Current Rating - Parallel | 2 A |
| Current Rating - Series | 1 A |
| Current Saturation - Parallel | 4.1 A |
| Current Saturation - Series | 2 A |
| DC Resistance (DCR) - Parallel | 140mOhm Max |
| DC Resistance (DCR) - Series | 570mOhm Max |
|
