| Part number: | SP8M7FU6TB |
| Description: | MOSFET N/P-CH 30V 5A/7A 8SOP |
| Manufacturer | ROHM Semiconductor |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 2500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "ROHM Semiconductor" |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Configuration | N and P-Channel |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 2W |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 5A, 7A |
| Input Capacitance (Ciss) (Max) @ Vds | 230pF @ 10V |
| Rds On (Max) @ Id, Vgs | 51mOhm @ 5A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 5.5nC @ 5V |
| FET Feature | Logic Level Gate |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Supplier Device Package | 8-SOP |
|
