| Part number: | 126B |
| Description: | AUDIO XFMR 5K / 5K CHAS MNT |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Box |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 3.120" L x 2.500" W (79.25mm x 63.50mm) |
| Mounting Type | Chassis Mount |
| Termination Style | Wire Leads |
| Transformer Type | Single Ended Audiophile, Ultra-Linear - Tube Output |
| Frequency Range | 20Hz ~ 20kHz |
| Voltage - Isolation | 400VDC |
| Height - Seated (Max) | 3.120" (79.25mm) |
| Impedance - Primary (Ohms) | 5k |
| Impedance - Secondary (Ohms) | 5k |
| DC Resistance (DCR) - Primary | 178Ohm |
| DC Resistance (DCR) - Secondary | 178Ohm |
| Frequency Response | ±1dB |
| Power Level | 4W |
|
