| Part number: | 1760L |
| Description: | XFMR 4.2KCT / 4, 8, 16 CHAS MNT |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Box |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 4.050" L x 3.150" W (102.87mm x 80.01mm) |
| Mounting Type | Chassis Mount |
| Termination Style | Wire Leads |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output |
| Turns Ratio - Primary:Secondary | 31.16:1 |
| Frequency Range | 70Hz ~ 15kHz |
| Height - Seated (Max) | 3.193" (81.10mm) |
| Impedance - Primary (Ohms) | 4.2kCT |
| Impedance - Secondary (Ohms) | 4, 8, 16 |
| DC Resistance (DCR) - Primary | 46.48Ohm, 51.04Ohm |
| DC Resistance (DCR) - Secondary | 252mOhm, 480mOhm, 714mOhm |
| Frequency Response | ±1dB |
| Power Level | 60W |
|
