| Part number: | SRF0703-151M |
| Description: | INDUCT ARRAY 2 COIL 150UH SMD |
| Manufacturer | J.W. Miller / Bourns |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "J.W. Miller / Bourns" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.299" L x 0.299" W (7.60mm x 7.60mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| Height | 0.142" (3.60mm) |
| Number of Coils | 2 |
| Inductance - Connected In Series | 600 µH |
| Inductance - Connected In Parallel | 150 µH |
| Current Rating - Parallel | 580 mA |
| Current Rating - Series | 289 mA |
| Current Saturation - Parallel | 650 mA |
| Current Saturation - Series | 320 mA |
| DC Resistance (DCR) - Parallel | 986mOhm Max |
| DC Resistance (DCR) - Series | 3.63Ohm Max |
|
