| Part number: | SRF1260-681M |
| Description: | INDUCT ARRAY 2 COIL 680UH SMD |
| Manufacturer | J.W. Miller / Bourns |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 400 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "J.W. Miller / Bourns" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| Height | 0.244" (6.20mm) |
| Number of Coils | 2 |
| Inductance - Connected In Series | 2.72 mH |
| Inductance - Connected In Parallel | 680 µH |
| Current Rating - Parallel | 700 mA |
| Current Rating - Series | 350 mA |
| Current Saturation - Parallel | 850 mA |
| Current Saturation - Series | 425 mA |
| DC Resistance (DCR) - Parallel | 1.212Ohm Max |
| DC Resistance (DCR) - Series | 4.635Ohm Max |
|
