| Part number: | 0157.315DR |
| Description: | FUSE BRD MT 315MA 125VAC/VDC SMD |
| Manufacturer | Wickmann / Littelfuse |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Wickmann / Littelfuse" |
| Package / Case | 2-SMD, Square End Block with Clip |
| Size / Dimension | 0.256" L x 0.146" W x 0.154" H (6.50mm x 3.70mm x 3.90mm) |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Mounting Type | Requires Holder, Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Response Time | Fast Blow |
| Approval Agency | cULus |
| DC Cold Resistance | 0.3881 Ohms |
| Breaking Capacity @ Rated Voltage | 50A |
| Current Rating (Amps) | 315 mA |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 125 V |
| Melting I²t | 0.0311 |
|
