| Part number: | DSK5J01P0L |
| Description: | JFET N-CH 30MA SMINI3-F2 |
| Manufacturer | Panasonic Electronic Components |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Panasonic Electronic Components" |
| Package / Case | SC-85 |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| FET Type | N-Channel |
| Input Capacitance (Ciss) (Max) @ Vds | 6pF @ 10V |
| Current Drain (Id) - Max | 30 mA |
| Supplier Device Package | SMini3-F2-B |
| Drain to Source Voltage (Vdss) | 55 V |
| Power - Max | 150 mW |
| Voltage - Cutoff (VGS off) @ Id | 5 V @ 10 µA |
| Current - Drain (Idss) @ Vds (Vgs=0) | 1 mA @ 10 V |
|
