| Part number: | SN74LV132ADBR |
| Description: | IC GATE NAND 4CH 2-INP 14SSOP |
| Manufacturer | Texas Instruments |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 2000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Texas Instruments" |
| Features | Schmitt Trigger |
| Package / Case | 14-SSOP (0.209", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Logic Type | NAND Gate |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Output High, Low | 12mA, 12mA |
| Number of Inputs | 2 |
| Supplier Device Package | 14-SSOP |
| Input Logic Level - High | 1.75V ~ 3.5V |
| Input Logic Level - Low | 0.75V ~ 1.5V |
| Max Propagation Delay @ V, Max CL | 9.7ns @ 5V, 50pF |
| Number of Circuits | 4 |
| Current - Quiescent (Max) | 20 µA |
|
