| Part number: | PM30-12T0512 |
| Description: | DC DC CONVERTER 5V +/-12V 30W |
| Manufacturer | TDK-Lambda, Inc. |
| Encapsulation | - |
| Quantity | 1 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "TDK-Lambda, Inc." |
| Package / Case | 9-DIP Module, 8 Leads |
| Size / Dimension | 3.00" L x 2.50" W x 0.33" H (76.2mm x 63.5mm x 8.4mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 50°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 18V |
| Current - Output (Max) | 5A, 1A, 1A |
| Voltage - Input (Min) | 9V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 12V |
| Voltage - Output 3 | -12V |
| Power (Watts) | 30 W |
| Number of Outputs | 3 |
| Voltage - Isolation | 700 V |
|
