| Part number: | 850H |
| Description: | XFMR 600 150/150 / 1.2K, 300/300 |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 1.700" L x 1.200" W (43.18mm x 30.48mm) |
| Mounting Type | Chassis Mount |
| Termination Style | Solder Lug |
| Transformer Type | Broadcast Quality |
| Insertion Loss | 1dB |
| Frequency Range | 20Hz ~ 20kHz |
| Height - Seated (Max) | 1.650" (41.91mm) |
| Impedance - Primary (Ohms) | 600, 150/150 |
| Impedance - Secondary (Ohms) | 1.2k, 300/300 |
| DC Resistance (DCR) - Primary | 70Ohm |
| DC Resistance (DCR) - Secondary | 140Ohm |
| Frequency Response | ±0.5dB |
| Power Level | 15dB |
|
