| Part number: | 107X |
| Description: | AUDIO XFMR 100KCT / 1KCT TH |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 0.630" L x 0.586" W (16.00mm x 14.88mm) |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Transformer Type | Miniature Epoxy Potted |
| Turns Ratio - Primary:Secondary | 10:1 |
| Frequency Range | 300Hz ~ 50kHz |
| Voltage - Isolation | 500Vrms |
| Height - Seated (Max) | 0.630" (16.00mm) |
| Impedance - Primary (Ohms) | 100kCT |
| Impedance - Secondary (Ohms) | 1kCT |
| DC Resistance (DCR) - Primary | 3.66kOhm |
| DC Resistance (DCR) - Secondary | 75Ohm |
| Frequency Response | ±1.5dB |
| Power Level | 150mW |
|
