| Part number: | TYS8040101M-10 |
| Description: | FIXED IND 100UH 1A 290 MOHM SMD |
| Manufacturer | Laird-Signal Integrity Products |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Laird-Signal Integrity Products" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.315" L x 0.315" W (8.00mm x 8.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 290mOhm Max |
| Frequency - Self Resonant | 4.2MHz |
| Current - Saturation (Isat) | 1.15A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.165" (4.20mm) |
| Inductance | 100 µH |
| Current Rating (Amps) | 1 A |
|
