| Part number: | 0498220000 |
| Description: | TERM BLK POST SNGL 1POS 18.0MM |
| Manufacturer | Weidmuller |
| Encapsulation | Bulk |
| Quantity | 25 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Weidmuller" |
| Mounting Type | DIN Rail |
| Length | 1.575" (40.01mm) |
| Type | Post - Single |
| Termination Style | Stud |
| Material - Insulation | Gemin (Thermosetting Plastic) |
| Number of Levels | 1 |
| Terminal - Width | 18.0mm |
| Wire Gauge or Range - AWG | 4-12 AWG |
| Wire Gauge or Range - mm² | 16mm² |
| Height (Max) | 2.441" (62.00mm) |
| Housing Color | Yellow |
| Current - UL | 85 A |
| Current - IEC | 76 A |
| Voltage - IEC | 1 kV |
| Voltage - UL | 600 V |
| Number of Positions | 1 |
|
