| Part number: | 1011580000 |
| Description: | TERM BLK BUS BAR 2POS 5.0MM BLUE |
| Manufacturer | Weidmuller |
| Encapsulation | |
| Quantity | 100 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Weidmuller" |
| Mounting Type | DIN Rail |
| Length | 2.362" (60.00mm) |
| Type | Bus Bar - Side |
| Termination Style | Special, Hybrid |
| Material - Insulation | Thermoplastic, Wemid |
| Number of Levels | 1 |
| Terminal - Width | 5.0mm |
| Wire Gauge or Range - AWG | 12-22 AWG |
| Wire Gauge or Range - mm² | 2.5mm² |
| Height (Max) | 1.850" (47.00mm) |
| Housing Color | Blue |
| Stripping Length | 10mm |
| Current - UL | 25 A |
| Current - IEC | 24 A |
| Voltage - IEC | 400 V |
| Voltage - UL | 600 V |
| Number of Positions | 2 |
|
