| Part number: | ANT-G30B108111 |
| Description: | RF ANT 700/850MHZ WHIP STR PANEL |
| Manufacturer | Red Lion |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Red Lion" |
| Features | Cable - 1m |
| Mounting Type | Panel Mount |
| Frequency Range | 700MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.483GHz, 2.5GHz ~ 2.8GHz |
| Applications | CDMA, DCS, EDGE, GPRS, GSM, HSDPA, IMT, LTE, UMTS, WCDMA |
| Gain | 1.2dBi, 3.2dBi, 2.5dBi, 1.5dBi |
| Termination | SMA Male |
| Ingress Protection | IP67, IP69K |
| Number of Bands | 4 |
| VSWR | 3 |
| Antenna Type | Whip, Straight |
| Height (Max) | 1.890" (48.00mm) |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz |
| RF Family/Standard | Cellular |
| Power - Max | 5 W |
|
