| Part number: | 691236610002 |
| Description: | TERM BLK 2P SIDE ENT 10.16MM PCB |
| Manufacturer | Würth Elektronik Midcom |
| Encapsulation | Bulk |
| Quantity | 25 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Würth Elektronik Midcom" |
| Features | Interlocking (Side) |
| Color | Green |
| Mounting Type | Through Hole |
| Wire Gauge | 12-30 AWG |
| Pitch | 0.400" (10.16mm) |
| Operating Temperature | -30°C ~ 120°C |
| Mating Orientation | Horizontal with Board |
| Positions Per Level | 2 |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Material - Plating | Copper Alloy - Nickel Plated |
| Clamp Material - Plating | Copper Alloy |
| Screw Material - Plating | Zinc Plated |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Screw Thread | M3 |
| Wire Termination | Screw - Rising Cage Clamp |
| Current | 20 A |
| Number of Levels | 1 |
| Voltage | 300 V |
|
