| Part number: | STMGFW152412-N2 |
| Description: | DC/DC CONVERTER +/-12V 16W |
| Manufacturer | Cosel |
| Encapsulation | Box |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Cosel" |
| Power (Watts) | 16W |
| Size / Dimension | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) |
| Mounting Type | Chassis Mount |
| Type | Open Frame |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Approval Agency | CE |
| Efficiency | 88% |
| Current - Output (Max) | 650mA, 650mA |
| Voltage - Input (Min) | 9V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Number of Outputs | 2 |
| Voltage - Isolation | 1.5 kV |
|
