| Part number: | ST2042BD |
| Description: | IC PWR SWITCH N-CHANNEL 1:2 8SO |
| Manufacturer | STMicroelectronics |
| Encapsulation | Tube |
| Quantity | 100 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "STMicroelectronics" |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Interface | On/Off |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 80mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Ratio - Input:Output | 1:2 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
|
