| Part number: | LSH1-04C22-5080-00 |
| Description: | LED MOD XHP50.2 WH LNR STR 5000K |
| Manufacturer | New Energy |
| Encapsulation | Tray |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "New Energy" |
| Color | White, Cool |
| Size / Dimension | 170.18mm L x 32.99mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 44.8V |
| Height | 1.52mm |
| Current - Test | 700mA |
| Lens Type | Domed |
| Current - Max | 1.5A |
| Lumens/Watt @ Current - Test | 143 lm/W |
| CCT (K) | 5000K 5-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 80 |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 4480lm |
|
