| Part number: | EM392302 |
| Description: | EUROMAG 3923 SERIES 2 POLE |
| Manufacturer | PowerStor (Eaton) |
| Encapsulation | Bulk |
| Quantity | 100 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "PowerStor (Eaton)" |
| Features | Interlocking (Side) |
| Color | Green |
| Mounting Type | Through Hole |
| Wire Gauge | 16-26 AWG |
| Pitch | 0.138" (3.50mm) |
| Operating Temperature | -40°C ~ 105°C |
| Mating Orientation | Horizontal with Board |
| Positions Per Level | 2 |
| Housing Material | Thermoplastic |
| Contact Material - Plating | Brass - Tin Plated |
| Clamp Material - Plating | Brass - Nickel Plated |
| Screw Material - Plating | Steel - Zinc Plated |
| Torque - Screw | 0.17 Nm (1.5 Lb-In) |
| Screw Thread | M2 |
| Wire Termination | Screw - Rising Cage Clamp |
| Current | 10 A |
| Number of Levels | 1 |
| Voltage | 300 V |
|
