| Part number: | 125CDMCCDS-R36MC |
| Description: | FIXED IND 360NH 40A 0.95MOHM SMD |
| Manufacturer | Sumida Corporation |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 500 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Sumida Corporation" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.530" L x 0.496" W (13.45mm x 12.60mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 0.95mOhm Max |
| Current - Saturation (Isat) | 80A |
| Material - Core | Metal |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | SMD |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Inductance | 360 nH |
| Current Rating (Amps) | 40 A |
|
