| Part number: | 14A-56-24 |
| Description: | PWR XFMR LAMINATED 56VA TH |
| Manufacturer | Signal Transformer |
| Encapsulation | Box |
| Quantity | 20 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Signal Transformer" |
| Size / Dimension | 76.20mm L x 63.50mm W |
| Mounting Type | Through Hole |
| Type | Laminated Core |
| Weight | 1.7 lbs (771.1 g) |
| Termination Style | PC Pin |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Power - Max | 56VA |
| Voltage - Isolation | 4000Vrms |
| Current - Output (Max) | Parallel 4.66A, Series 2.33A |
| Voltage - Primary | 115V, 230V |
| Height - Seated (Max) | 46.00mm |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V |
| Center Tap | No |
|
